PSR Security

Part #: SkyRadar PSR-Security-Ver.4.1

Get a PDF version of this webpage PDF

The Security module is part of SkyRadar’s Radar Training System. It builds on the PSR Module and is made for homeland security and military oriented radar training. It allows training on Electronic Counter Measures as well as Electronic Counter Counter Measures.

SkyRadar Security
SkyRadar Security

The Security Module consists of:

  • Electronic Counter Counter Measure Functionalities (ECCM) (software as add-on to the SkyRadar Navigator.
  • One (1) Computer-controlled hardware for Electronic Counter Measures (ECM)
  • One (1) Laptop with SkyRadar Security Software installed
  • One (1) CD-ROM with SkyRadar Security software installation pack
  • One (1) software license

The Security Module comprises of a hardware based target generator, which is able to create ghost targets. The system is connected to a Laptop. Supported by a configuration software, it serves as hardware jammer to create disturbances. The Security Module further includes Electronics Counter Counter Measure functionalities (ECCM), which are implemented as additional software licenses to the SkyRadar Navigator. Various exercises can be conducted on the system to react on the multiple possible attack strategies and ghost targets.

SkyRadar Security Hardware Features

Parameter Range Unit
Frequency range

24,000 – 24.250

GHz
Doppler frequency range

44 – 8600

Hz
Simulated speed range

1 – 200

Km/h
Output power range

1 – 100

%
Antenna gain

14

dBi
Antenna polarization

RHCP


Overall gain

32 -36

dB
Operating temperature

0 – 60

°C
Supply current battery

6

V
Supply currnet USB

5

V
SkyRadar Security
SkyRadar Security

SkyRadar Security Software Features

  • Electronic Counter Measure System (ECM), accomplished, piloting the hardware of the ghost-target generator
    • Diverse functionalities.
    • Comfortable HMI.
    • Allowing for various and ECM exercises.
    • Electronic Counter Counter Measure software
      • Diverse functionalities.
      • Comfortable HMI.
      • Allowing for various cross section and ECCM exercises, i.e. the identification of ghost targets as well as the handling of malicious disturbances.

Contact us and ask for SkyRadar’s modular radar training system.
