SkyRadar's 8 GHz Pulse radar emits in the X-band, the band used by ATC Area Control Radars, but also by the military and the navy. The transmitter can emit very short pulses through the antenna and monitor the reflected pulses. The pulses are reflected of fixed and moving objects.
The radar provides the data as I/Q data. This raw data can be processed individually and concurrently by many students in a special digital signal processing (dsp) control and visualization center called "SkyRadar FreeScopes". Students have access to FreeScopes via their browsers.
With a range resolution of ~ 10 cm and a pulse width of 0.5 nsec it is the most accurate training pulse radar in the market. The number of concurrent users practicing independently is not limited.
Some general features of the NextGen 8 GHz Pulse training radar:
The name "NextGen" is inspired by the European ATM-master plan as well as the ICAO Global Air Navigation Plan. The two major aviation innovation initiatives require next generation, service-oriented architecture to ensure sustainability and competitiveness of aviation in the 21st century. The NextGen system is service-oriented, modular, expandable and interoperable. It can be connected to many of SkyRadar's and 3rd party systems.
he following subjects can be trained with the system, depending on the included FreeScopes Packages:
The system can be supplied in a package with several extensions of FreeScopes or it can be extended progressively.
Examples are:
All Data can be transferred in real-time to a numerical analytics environment like MATLAB with SkyRadar's programming interface, which is part of
The hardware system can be extended with various elements like
Rotary Tripod, CloudServer, and more.
Look at our suggested reference configurations such as
We also suggest package-priced solutions.
Overview of the key technical features:
|
Power Requirements
|
12V, 5V
|
|
Maximum Range
|
10 m |
|
Maximum Sampling Rate Rx
|
23.3 GS/s
|
|
Dimensions
|
140 mm x 143mm x 200 mm
|
|
Net Weight
|
below 5 kg
|
Table: Key system features
Major transmitter features are:
| Supply Current | 100 mA |
| Operating Ambient Temperature | + 10 … + 40 °C |
Table: General operative characteristics of the Transceiver
| Parameter | Min | Typ | Max |
| Transmitter Center Frequency (ETSI / KCC) | 7.29 GHz / 8.748 GHz | ||
| Transmitter Bandwidth (ETSI / KCC) | 1.4 GHz / 1.5 GHz | ||
| Energy per Pulse (ETSI) | 0.45 pJ | 1.47 pJ | 2.6 pJ |
| Peak Pulse Output Power (ETSI) | - 0.7 dBm (0.8 mW) | 4.1 dBm (2.6mW) | 6.3 dBm (4.3 mW) |
| Pulse Repetition Frequency | 15.2 MHz | ||
| Differential Output Impedance | 100 Ohm |
Table : Operative characteristics of the Transmitter (subsection of the Transceiver)
Major receiver features are:
| Parameter | Min | Typ | Max |
| Radar Frame Length | 9.87 m / 65.8 ns | ||
| Sampling Rate | 23.328 GS/s | ||
| Receiver Gain (ETSI) | 12.3 dB | 14.1 dB | 15.0 dB |
| Receiver Noise Figure (ETSI) | 5.4 dB | 6.8 dB | 8.8 dB |
| Receiver Bandwidth (- 3 dB), Flow | 6.13 GHz | 6.5 GHz | |
| Receiver Bandwidth (- 3 dB), Fhigh | 10.0 GHz | 10.76 GHz | |
| Differential Input Impedance | 100 | Ohm |
Antenna Features (including the Parabolic Reflector, offset: 24 cm canonical distance, 84 cm diameter)
|
Parameter
|
Typ.
|
|
Antenna Gain
|
33 dB
|
|
Azimuth beam width (at -3dB)
|
5°
|
|
Elevation beam width (at -3dB)
|
5° |
Table : Operative characteristics of the antenna including the parabolic reflector
SkyRadar produces products to train the civil use of radar equipment. We do not include Electronic Warfare Products in our portfolio. We actively take that mission to makes this world a better and safer place. We do not provide goods which are in conflict of the dual use regulation (unless with specific written consent of the European Regulation Bodies and if the purpose is a peaceful one).
SkyRadar emphasizes that the COUNCIL REGULATION (EC) No 428/2009 and its amendments are the only authentic legal reference and that the information in this document does not constitute legal advice.
According Paragraph 6A008, goods are subject to the above stated Regulation, when they comply to the following criteria:
|
Criteria |
Explanation why SkyRadar does not comply to these criteria |
|
a. Operating at frequencies from 40 GHz to 230 GHz and having any of the following: ... |
The system operates at 8 GHz and operates far below the critical threshold |
|
b. A tunable bandwidth exceeding ± 6,25 % of the 'centre operating frequency' |
The bandwidth is not tunable is far below critical frequency value |
|
c. Capable of operating simultaneously on more than two carrier frequencies |
The system operates with one carrier frequency |
|
d. Capable of operating in synthetic aperture (SAR), inverse synthetic aperture (ISAR) radar mode, or sidelooking airborne (SLAR) radar mode |
The base module itself does not include SAR, iSAR or SLAR features. SkyRadar is committed not to provide attack technologies. Airborne radar technology will never be produced by SkyRadar |
|
e. Incorporating electronically scanned array antennae |
The system does not work with electronically scanned array antennae. It operates with a horn-shaped antenna or a patch antenna. |
The dual use regulation, in particular paragraph 6A008 does not include "Displays or monitors used for air traffic control (ATC)", as done by SkyRadar FreeScopes.
Section l.1 of paragraph 6A008 addresses "Automatic target tracking" providing, at any antenna rotation, the predicted target position beyond the time of the next antenna beam passage. This paragraph however does not "control conflict alert capability in ATC systems". Only that is done by the SkyRadar FreeScopes software. Target tracking in terms of trajectory projection, as done by military systems is explicitly excluded and not part of the system.
Paragraph 6A108 concerns Radar systems and tracking systems, other than those specified in entry 6A008. It covers Radar and laser radar systems designed or modified for use in space launch vehicles specified in 9A004 or sounding rockets specified in 9A104. This is not applicable to the SkyRadar training equipment.
SkyRadar's base unit is a close range training and research radar for indoor and outdoor experiments.
